Cisco D9854 User Manual

5-54 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Setting up Services: Subtitles
To Set Up Subtitles for Services
Proceed as follows to set up the subtitles:
1. From the user interface of the D9854, click the Setup tab, expand Services, and
then click the Subtitles icon from the sub-page.
2. Select the Subtitle mode to use to display the program subtitles. The following
table describes each of the available options:
Op Mode Selection Description
Off No subtitles are displayed.
On Functions as an “Auto” setting. DVB subtitles are
displayed when only DVB subtitles are transmitted on
the channel, and likewise, Imitext subtitles are
displayed when only Imitext subtitles are transmitted
on the channel. When both DVB and Imitext subtitles
are available on the same channel, only DVB subtitles
will be displayed.
DVB Displays only DVB titles. For example, if DVB is
selected, but both DVB and Imitext titles are being
transmitted on the same channel, only DVB subtitles
will be displayed.
Imitext Displays only Imitext subtitles. For example, if Imitext
is selected, but both DVB and Imitext titles are being
transmitted on the same channel, only Imitext subtitles
will be displayed.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
