5-20 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Viewing the Audio Status
To View the Audio Status
Proceed as follows to view the Audio Status page:
From the user interface of the D9854, click the Status tab, expand Services, and then
click Audio icon from the sub-page.
The following table describes the Audio Status information displayed:
Audio Status Description
Source The audio channel within the stream when the
signal contains more than two audio pairs.
AUD1 for audio channel Aud1.
AUD2 for audio channel Aud2.
AUD1 to AUD4 for two stereo audio channels.
Audio Format The received audio channel format (MPEG, AC3,
AAC, HEAAC or DDP).
Bit Rate (Kbps) Audio bit rate of the received audio channel, in
kbps.
Buffer Level (Bytes) The audio input buffer level, in bytes.
Sampling Frequency
(Hz)
The audio sampling frequency (32, 44.1, or 48 Hz).

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
