5-10 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Viewing the CA Status
To View the CA Status
Proceed as follows to view the CA Status page:
From the user interface of the D9854, click the Status tab, and then the CA Status
icon from the sub-page.
The following describes the columns in the CA Status table:
Status Description
Index The ISE number.
ISE User Address The ISE User Address. It consists of 14 hexadecimal
characters.
ISE Version Number The ISE version number. It consists of 7 characters.
Enc Data pkts passed Current Encrypted Addressed Data Packet Count.
This count indicates the amount of transmitted ADP
information which is being accurately received and
processed. Ideally, the ADP Enc Pass and ADP Enc
Total numbers should be identical.
Enc Data pkts recvd The total number of current Encrypted Addressed
Data Packet count. This count indicates the amount
of transmitted ADP information being accurately
received and processed. Ideally, the ADP Enc Pass
and ADP Enc Total numbers should be identical.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
