5-40 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Configuring the Transport Stream: DPM Table Opt
To Set up the DPM Table Options
Proceed as follows to configure the DPM Table options:
Note: The following procedure defines all the available fields. For a typical setup of
the DPM, see Typical set up for Digital Program Mapping (DPM), page 5-42.
1. From the user interface of the D9854, click the Setup tab and then click the
TSOutput icon from the sub-page and select DPM Table Opt radio button.
Note: Any changes made to the DPM Table Options configuration
automatically changes the Output Mode to Full DPM Control in the Transport
Stream Configuration page.
When you initially make a change, the page refreshes and the Transport Stream
Configuration page appears with the Output Mode changed to Full DPM
Control. Click Save and continue to edit the DPM Table parameters.
2. Select the tables which will be passed, dropped, regenerated or passed with rate
control (PwRC) from the ASI or MOIP Output.
Setting
Mode Options Description Default
PAT Pass, Drop, Regen Program Allocation Table Pass
CAT Pass, Drop, Regen Conditional Access Table Pass
PMT Pass, Drop, Regen Program Map Table Pass
TSDT Pass, Drop Transport Section Description
Table
Pass
