4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 4-25
Setup Menu
Structure
To view the Setup menu from the Main menu, press the RIGHT arrow key once and
the SELECT key. The Setup menu is split into nine parts; Administration, TS Input,
IP, Services, CI, Outputs, CA, Alarms/Warnings, and Noise Cutoff. For instructions
on how to select and store settings, see About the Front Panel, page 4-2.
The Setup menu allows you to set all the parameters associated with the following:
• Administration - lock level, password, factory reset, keypad lock, download
mode and date and time
• TS Input - frequency parameters for acquiring and locking on to an RF signal, or
receiving an ASI input
• IP - parameters for setting up the Ethernet ports
• Services - audio video, captions, and VBI
• CI - parameters to decrypt programming available from service provider
programmers via CAM Smart Cards
• Outputs - parameters for setting up the transport stream out, which includes
DPM and transcoding
• CA - conditional access
• Alarms/Warnings - enables alarms/warnings traps and relays
• Noise Cutoff - muting thresholds
The Setup menu has the following structure:
Main:Setup 1/2
Admin TS Input IP Services CI
i
s
Main:Setup 2/2
Outputs CA Alarm/Warning NoiseCutoff
i
s
To Next Page
