Section C - Transport Stream Outputs
ASI Output
MPEGoIP Output (optional)
MPE Output
Item Specification
Number of outputs 1
Type of connector 75 Ω BNC
Output impedance 75 Ω according to EN 50083-9
Data amplitude 800 mV peak-peak ± 10% according to EN
50083-9
Return loss >17 dB, 27 to 270 MHz
Transport stream bit rate 1 to 120 Mbit/s ± 100 ppm
ASI bit rate 200 Mbit/s ± 100 ppm
Transport stream formats According to EN 50083-9.
188 bytes structure,
204 bytes without Reed Solomon,
Burst or packet format.
Item Specification
Number of outputs 1
Type of connector RJ-45, 10/100/1000 BaseT
Output modes UDP RAW, RTP
IP Addressing Multicast
TS Streaming MPTS
TS Bit Rate 1 to 120 Mbps
Item Specification
Number of outputs 1
Type of connector RJ-45, 10/100/1000 BaseT
Output modes IPv4 datagrams
IP Addressing Multicast, up to 5 addresses
TS Input up to 5 PIDs
Bit Rate up to 10 Mbps (for 1500 byte packets)

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
