Cisco D9854 User Manual

5-18 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Viewing the Services Status
To View the Services Status
Proceed as follows to view the Services page:
From the user interface of the D9854, click the Status tab, and then click Services
icon from the sub-page.
The following table describes the channel information displayed:
Channel Information Description
PE Indicates the Program Entry number (PE1 to PE16).
Channel Displays the input channel of the current PE. The
channel is displayed in a range from 1 to 65535.
CAID Indicates the Conditional Access (CA) system used
for the received signal (SA, BISS, or Unknown).
Auth Indicates whether the receiver is authorized to
receive the signal (Yes or No).
Enc Indicates whether the received signal is encrypted
(Yes or No).
Scr Indicates whether the received signal is scrambled
(Yes or No).

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
