4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 5-17
Output Mode
Null Pkts Displays whether to insert null packets in the output
stream (Yes or No).
Null Rate (Mbps) The null packet rate, in Mbps.
Protocol The transport protocol used for the output stream
(RTP or UDP).
Dest The multicast destination IP address. The field
displays a range from 0 to 255, in the format
###.###.###.###.
Src Port The source UDP port number, in the range from 1 to
65535.
Dest Port The destination port number, in the range from 1 to
65535.
SAP Dest The SAP destination IP address. The field displays a
range from 0 to 255, in the format ###.###.###.###.
SAP String This is the SAP identifier (ID)/string. It displays up
to 49 characters.
MPEGoIP Output
Status
Description
Output Mode Description
No Output No ASI output will be generated.
Passthrough The output will be identical to the input. The output
channel will not be modified.
PE/PID remapping options, PSI regeneration and User
Rate are not supported in this mode.
Service Chans Only Only service channels will be output.
MAP Passthrough The output will be identical to the input, except that it
will be generated using the DPM and PID mapping
settings.
MAP Svc Chans
Only
Only service channels will be output according to the
DPM and PID mapping settings.
Full DPM Control The output will be generated according to the DPM
settings on the DPM: ASI or MOIP1 menus. This is a
manual control setting.
