4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 5-25
Setting up the TS Input, Continued
16. Select the signal Polarisation setting (Horizontal, Vertical, or Automatic). This
setting is only applicable when the LNB Power is set to H-NIT or V-NIT. The
selected setting must match the polarisation of the transmitted signal.
17. Select the EW Flag for RF1, RF2, RF3, or RF4. This is the satellite position the
dish connected to the current RF Input should point. The options are East, West,
or Not Applicable.
18. Select the signal Polarisation setting. This setting is only applicable when LNB
Power is set to H-NIT or V-NIT. The selected setting must match the
polarization of the transmitted signal. You can set the signal to H (Horizontal), V
(Vertical) or A (Auto).
19. Select UserCfg in the Input Selection to lock to the RF input set by the user.
Select SW Map to use the orbital position settings to select the RF input. It is
recommended that you validate the orbital position for SW Map option.
20. The LNB Power setting determines if power is provided via the RF1 Input to an
external LNB connection.
You can set the LNB Power to Off, 13V, 18V, V-NIT or H-NIT. When LNB Power
is set to V-NIT or H-NIT, the signal polarization is automatically read from the
NIT.
Note: Power will not be applied to the LNB when Power is set to Off.
21. The RF1 22KHz is only applicable for dual-band LNB applications. It sets
whether or not the 22 kHz tone is available on the RF1. The selections are On,
Off, or Auto (actual presence of 22 KHz control signal depends on whether
downlink frequency is greater than the crossover frequency).
22. Click Apply.
23. Click Validate to validate the RF inputs to match those expected by the network.
The receiver will check to see if all frequencies in the Network Information Table
(NIT) can be tuned to. The Date is displayed as the last date that the Validate
operation was performed.
