4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 4-81
Setup Menu: Outputs: TS Out: DPM, Continued
Setting Up Digital Program Mapping (DPM)
To set up DPM:
1. Verify that you are receiving a valid signal and that you have set up the
channels that you want to pass, drop or map.
2. Go to the Setup: Outputs, TS Out: DPM: Global menu and select Resync All for
the selected output, ASI or MOIP1. This copies the input services PIDs to the
remapped output service PIDs.
3. Go to Setup: Outputs: TS Out: DPM: ASI, and select the PE containing the
channel you want to configure.
4. Set the Act for the selected PMT to either Pass, Drop, or Map depending on the
action desired.
5. Use the RIGHT arrow key to move to the right and select PID to display the
detailed menu level.
6. Configure the input to output channel mapping. Video and PCR can be output
on the same PID or different PIDs. If output on the same PID, they will appear
identical to the input. The example below shows the PMT passed, but the
services PIDs remapped.
Note: If the parameters cannot be saved, the problem may be that the incorrect
Map Mode has been selected. Ensure that Svc ID & PID is selected when
remapping PIDs, otherwise a message such as “Bad configuration data” will be
displayed and you will need to change the parameters to obtain the correct
output.
7. Go to Setup: Outputs, TS Out: ASI, and set the Output Mode to Full DPM
Control. Also, if necessary set the Descramble Mode according to whether the
program is to be Scrambled or Descrambled for downstream viewing/
monitoring.
PE InCh PMT Act OutCh PMT PID
1 205 5001 Pass 204 5001
i
s
InTyp In PID Act OutType In PID
VID 4 2001 Map VID 4 2004
i
s
Change Action
PID remapped
To Next Page
