4021470 Rev D Model D9854 Advanced Program Receiver Installation and Operation Guide 5-1
Chapter 5
Setup and Monitoring
Overview
In This Chapter
This chapter contains the following topics.
Topic See Page
Logging On to the Web Interface 5-3
Web Interface - Summary Screen 5-4
Tab Pages 5-5
Viewing the Input and Output Status 5-7
Viewing the Alarm and Warning Messages 5-9
Viewing the CA Status 5-10
Viewing the CI Status 5-12
Viewing the Input Status 5-13
Viewing the Output Status 5-16
Viewing the Services Status 5-18
Viewing the Audio Status 5-20
Viewing the Video Status 5-21
Setting up the TS Input 5-23
Setting up Custom Tuning Parameters 5-26
Setting up the Program Entry Configurations 5-27
Setting up the BISS Mode 5-28
Configuring the Common Interface (CI) Information 5-29
Setting up the Common Interface: CI Components 5-31
Configuring the Transport Stream: TS Output 5-33
Configuring the Transport Stream: DPM Global 5-36
Configuring the Transport Stream: DPM ASI/MPEG Details 5-39
Configuring the Transport Stream: DPM Table Opt 5-40
Setting up the TS Output: MPEGoIP 5-45

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
