5-22 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Viewing the Video Status, Continued
The following table describes the Aspect Ratio Status information displayed:
Aspect Ratio Status Description
Stream The stream aspect ratio. This is the conversion that
the receiver will perform on the incoming signal for
the picture to be displayed correctly (i.e., to
correspond to the aspect ratio of your TV) on your
TV, based on your selection. The parameters are: 4:3,
14:9 or 16:9.
Out This is the aspect ratio of your TV. The parameters
are: 4:3 or 16:9 (wide aspect ratio). The default is 4:3.
Selection This is the conversion that the receiver will perform
on the incoming signal for the picture to be
displayed correctly (i.e., to correspond to the aspect
ratio of your TV) on your TV, based on your
selection. The parameters are: Auto, None, Auto
AFD (Auto setting using Active Format Descriptor),
16:9 L/B (letter box), 4:3 P/B (pillar box), 14:9, 4:3
CCO, 16:9 SCALE. The default is set to Auto.
Conversion This is the type of aspect ratio conversion that the
receiver will perform based on your selection (None,
4:3 L/B, 4:3 P/B, 14:9, 14:9, 4:3 F/H or 16:9 F/W).
