5-32 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Setting up the Common Interface: CI Components, Continued
4. There are various configurations when creating a new record.
5. The following table summarizes the various methods:
6. If you know the PID number, ensure that PID is selected under Mode and enter
the appropriate PID number. Click Save.
7. To enter the stream type, select Stream under Mode, select the stream type in
the Stream Category (Vid, Aud, Subt, or TTX) and enter the instance of the
stream type in Stream Instance. You can enter a range from 1 to 64. Click Save.
8. If you do not know the stream type, you can specify a specific hex value as the
stream type. Select Stream under Mode, select User under Stream Category,
enter the hex value of the stream under Stream Type value (hex) and the
instance of the customized stream type in Stream Instance. You can enter a two
digit hexadecimal value for the Stream Type and a range from 1 to 64 for the
Stream Instance. Click Save.
9. To delete a record, identify the record you want to remove and click Delete.
If you set by Parameter Settings
PID Set Mode to PID and enter PID number.
Stream Type Set Mode to Stream, select Stream Category (audio,
video, subtitle, ttx, or user) and enter Stream Instance of
the stream type.
There is an additional configuration if you select user as
the Stream Category (see below).
Stream Type: User Set Mode to Stream, Stream Category to User, manually
enter the stream code in Stream Type value (hex), and
then the Stream Instance of the stream type.
