5-34 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Configuring the Transport Stream: TS Output, Continued
4. Enter the output Rate, which is only used if Rate Control is set to User. This
setting is used when the signal source is RF or ASI.
Note: Output data may be lost when the user-selected bit rate is set to a value
that is less than the actual signal bit rate. This allows you to set the output bit
rate to a value expected by equipment connected to the ASI output.
You can enter a range from 0 to 213 Mbps for ASI and/or 0 to 999.99999 Mbps
for MOIP1.
5. Select the DPM output mode. The following table describes each mode:
6. In Descrambled drop-down, select whether the receiver should scramble the
output even if it is authorized to receive the channel. The default is
Descrambled.
Output Mode Description
No Output No ASI output will be generated.
Passthrough The output will be identical to the input. The output
channel will not be modified.
PE/PID remapping options, PSI regeneration and User
Rate are not supported in this mode.
Service Chans Only Only service channels will be output.
MAP Passthrough The output will be identical to the input, except that it
will be generated using the DPM and PID mapping
settings.
MAP Svc Chans
Only
Only service channels will be output according to the
DPM and PID mapping settings.
Full DPM Control The output will be generated according to the DPM
settings on the DPM: ASI or MOIP1 menus. This is a
manual control setting.
Descramble
Mode
Description
Scrambled Scrambles the output channel even if the PE is
authorized and can descramble the channel.
Descrambled Descrambles the output channel, and passes in-
the-clear channels.
