5-58 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Setting up the Video Service, Continued
7. Select the Wide Screen Signalling output mode. It is used to select how the
receiver affects PAL WSS when it is present in the VBI. The table below
describes each of the options. The default is Auto.
8. The Incoming Stream section indicates the encoding, bit rate, FPS and aspect
ratio of the incoming signal. The fields are read-only.
9. Click Save.
WSS Mode Description
Passthrough Passes WSS (unmodified, as received by the D9854
receiver) on VBI LIne 23 when present
Auto:Create Creates WSS to output the correct aspect ratio, when
performing aspect ratio conversion, otherwise it is
passed through.
Auto:Modify Modifies WSS to output the correct aspect ratio, when
performing aspect ratio conversion, otherwise it is
passed through
Suppress Disables Line 23 VBI processing. WSS is not output on
line 23.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
