4021470 Rev D D9854 Advanced Program Receiver Installation and Operation Guide 3-7
ASI Output One Asynchronous Serial Interface
Output.
BNC
Management For code downloading/application
upgrading for the D9854 receiver.
RJ45
HD-SDI Outputs M1 and M2 provide HD serial digital
video with embedded audio output
for HD applications according to
SMPTE 292M.
BNC
RS-232 Data RS-232 data output: 7 bits, even
parity, 1 stop bit, up to 38.4 kb/s.
These outputs are user-configurable
via the Setup menu on the front
panel.
9-pin sub-D female
Cue Tone/Cue
Trigger Relay
Outputs
Program relay provides
programmed responses for alarms,
cue trigger states for ad-insertion
equipment, or a cue tone output for
connection to ad-insertion
equipment.
15-pin sub-D female
Composite Video
Outputs
CVBS 1 and CVBS 2 provide two
identical SD composite video
outputs for monitoring applications.
BNC
Component Video
Outputs
SD to HD upconverted component
video output for HD monitoring
applications.
BNC
AES-3id Audio
Outputs
AES-3id outputs. One output for
each stereo channel.
BNC
Balanced Audio
Outputs
Audio 1 and Audio 2 provide two
stereo pairs or four mono channels.
Terminal Blocks
Ground Screw Grounding point for
the receiver.
Power AC power IEC 60320 Sheet 14
Connector Function Connector Type
