4-18 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Status Menu: Services, Continued
Format
Description: Indicates the received audio channel format.
Parameters: MPEG, AC3, AAC, HEAAC or DDP.
BR (Kbps)
Description: Indicates the audio bit rate of the received audio channel.
Parameters: in Kbps.
Buffer
Description: Indicates the audio input buffer level.
Parameters: in bytes.
SFR (Hz)
Description: Indicates the audio sampling frequency.
Parameters: 32, 44.1 or 48 Hz.
TS INPUT
INPUT
Input
Description: Indicates the active input port receiving the signal.
Parameters: RF1, RF2, RF3, RF4, or ASI.
Status
Description: Indicates the current signal lock status for the input.
Parameters: Signal Lock - See table.
Rate (Mbps)
Description: Indicates the bit rate of the received input signal.
Parameters: in Mbps.
Status Description
Locked Indicates the receiver is locked to a carrier
with no valid content.
Lock+Sig Indicates the receiver is locked to a carrier
with valid content.
No Lock Indicates the receiver is not locked to a
carrier.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
