4-36 Model D9854 Advanced Program Receiver Installation and Operation Guide 4021470 Rev D
Setup Menu: TS Input, Continued
22kHz
Description: This applicable for dual-band LNB applications. It sets whether or
not 22 kHz tone is available on RF1.
Parameters: On, Off or Auto (actual presence of 22 KHz control signal depends
on whether downlink frequency is greater than the crossover
frequency).
TUNE MODE
CUSTOM
Services List Mode
This menu is where you set up your custom and fixed PID properties (when Tune
Mode is Fixed PID). Select the channel to set up and then edit it.
Description: All of the options on this menu allow you to select which tables to
use to obtain tuning and channel lists. The values set on this menu
only apply when Tune Mode is set to Custom.
Parameters: Degraded or Rigorous. Rigorous means all the default settings must
be present in the received signal. Degraded means only the table
parameters present in the received signal will be used to install the
receiver. The default is Rigorous.
The following table shows some possible configurations for the
allowed service lists and the different frequency tuning settings.
Frequency Tuning
Description: Sets whether the receiver is to be tuned to the received signal using
the NITor a Preset.
Parameters: NIT or Preset.
Allowed Service Lists Custom Fixed PID
BAT N N
NIT N N
SDT N N
PAT Y N
Frequency Tuning Preset Preset
