46-7
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 46 Configuring the Switch Fabric Modules
Configuring and Monitoring the Integrated Switch Fabric and Switch Fabric Module on the Switch
This example shows how to display the module information:
Console> show module
Mod Slot Ports Module-Type Model Sub Status
--- ---- ----- ------------------------- ------------------- --- --------
1 1 2 1000BaseX Supervisor WS-X6K-SUP2-2GE yes ok
4 4 24 100BaseFX MM Ethernet WS-X6224-MM-MT no ok
5 5 0 Switch Fabric Module WS-C6500-SFM no ok
Mod Module-Name Serial-Num
--- ------------------- -----------
1 Munish
4 SAD02390156
5 SAD042818BR
Mod MAC-Address(es) Hw Fw Sw
--- -------------------------------------- ------ ---------- -----------------
1 00-40-0b-ff-00-00 to 00-40-0b-ff-00-01 0.219 6.1(0.146) 6.2(0.33-Eng)KEY
00-50-3e-7e-71-56 to 00-50-3e-7e-71-57
00-01-64-f8-ca-00 to 00-01-64-f8-cd-ff
4 00-10-7b-c2-3a-c0 to 00-10-7b-c2-3a-d7 0.204 4.2(0.24)V 6.2(0.14)KEY
5 00-40-0b-ff-00-00 0.204 6.1(0.133) 6.2(0.14)KEY
Mod Sub-Type Sub-Model Sub-Serial Sub-Hw
--- ----------------------- ------------------- ----------- ------
1 L3 Switching Engine II WS-F6K-PFC2 SAD04110B5S 0.305
Console> (enable)
Displaying the Fabric Channel Counters
To display the fabric channel counters, perform this task:
This example shows how to display the fabric channel counters:
Console> show fabric channel counters 5
Channel 0 counters:
0 rxTotalPkts = 0
1 txTotalPkts = 0
2 rxGoodPkts = 0
3 rxErrors = 0
4 txErrors = 0
5 txDropped = 0
Displaying the Fabric Channel Switching Mode and Channel Status
To display the fabric channel switching mode and channel status, perform this task:
Task Command
Display the fabric channel counters. show fabric channel counters {mod | all} [hex]
Task Command
Display the fabric channel switching mode and
channel status.
show fabric channel switchmode [mod]
