46-9
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 46 Configuring the Switch Fabric Modules
Configuring and Monitoring the Integrated Switch Fabric and Switch Fabric Module on the Switch
This example shows how to display the fabric channel utilization:
Console> show fabric channel utilization
Fab Chan Input Output
-------- ----- ------
Fab Chan Speed Input Output
-------- ----- ----- ------
0 n/a 0% 0%
1 n/a 0% 0%
2 n/a 0% 0%
3 n/a 0% 0%
4 20G 0% 0%
5 n/a 0% 0%
6 n/a 0% 0%
7 20G 0% 0%
8 8G 0% 0%
9 n/a 0% 0%
10 n/a 0% 0%
11 n/a 0% 0%
12 n/a 0% 0%
13 n/a 0% 0%
14 n/a 0% 0%
15 n/a 0% 0%
16 20G 0% 0%
17 n/a 0% 0%
Displaying the Fabric Errors
To display the fabric errors of one or all modules, perform this task:
This example shows how to display the fabric errors:
Console> (enable) show fabric errors all
Module errors:
Slot Channel CRC Hbeat Sync DDR sync
----- ---------- ---------- ---------- ---------- ----------
2 0 0 0 0 0
Fabric errors:
Slot Channel Sync Buffer Timeout
----- ---------- ---------- ---------- ----------
2 0 0 0 0
Console> (enable)
Task Command
Display the fabric errors. show fabric errors {mod | all}
