55-4
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 55 Configuring a VoIP Network
Understanding How a VoIP Network Works
Figure 55-2 Connecting the Cisco IP Phone 7960 to the Catalyst 6500 Series Switch
The examples shown in Figure 55-2 are described in detail as follows:
• Example 1: Single Cisco IP Phone 7960
Example 1 shows one IP phone that is connected to the 10/100 port on the Catalyst 6500 series
switch. The PC-to-phone jack on the phone is not used. The phone can be powered through the
10/100 port or wall powered.
• Example 2: Single PC
Example 2 shows one PC that is connected to the 10/100 port on the Catalyst 6500 series switch.
The PC is wall powered.
• Example 3: One Cisco IP Phone 7960 and One PC
Example 3 shows one IP phone that is connected to the 10/100 port on the Catalyst 6500 series
switch and one PC that is connected to the PC-to-phone jack on the phone. The PC behaves as if it
is connected directly to the 10/100 port on the Catalyst 6500 series switch. The phone can be
powered through the 10/100 port or wall powered. The PC must be wall powered.
• Example 4: Two Cisco IP Phone 7960s and One PC
Example 4 shows two IP phones that are connected to the 10/100 port on the Catalyst 6500 series
switch and one PC that is connected to the PC-to-phone jack on the phone. The PC behaves as if it
is connected directly to the 10/100 port on the Catalyst 6500 series switch. The first phone can be
powered through the 10/100 port or wall powered. The second phone and the PC must be wall
powered.
Note For more information on configuring the Cisco IP phones and third-party vendor phones, refer to the
documentation that shipped with the phone.
(WS-X6348-RJ45V)
10/100BASE-TX Module *
* Or any Catalyst 4000, 5000, and 6000
10/100 module using the inline-power
patch panel (WS-PWR-PNL)
(WS-X6348-RJ45V)
10/100BASE-TX Module
*
(WS-X6348-RJ45V)
10/100BASE-TX Module *
(WS-X6348-RJ45V)
10/100BASE-TX Module *
Gigabit Ethernet Module with
Inline power daughter card
(WS-6548-GE-TX + WS-F6K-VPWR)
*
Catalyst 6500 series switches
IP phone (Example 1)
PC (Example 2)
IP phone PC (Example 3)
IP phone IP phone
PC (Example 4)
38203
