55-19
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 55 Configuring a VoIP Network
Configuring VoIP on a Switch
This example shows how to display the detailed power status for the modules and individual ports:
Console> show port inlinepower 4/1 detail
Configured Default Inline Power allocation per port: 15.400 Watts (0.36
Amps @42V)
Total inline power drawn by module 4: 33.934 Watts ( 0.807 Amps @42V)
Port InlinePowered PowerAllocated Device IEEE class DiscoverMode
From PS To PD
Admin Oper Detected mWatts mWatts
----- ------ ------ -------- ------- ------- ---------- ---------- ------------
4/1 auto on yes 7079 6300 cisco none cisco
Port MaximumPower ActualConsumption absentCounter OverCurrent
mWatts mWatts
----- ------------ ----------------- ------------- -----------
4/1 15400 6300 0 0
Console>
Displaying the Switch Power Environment for Modules
To display the switch power environment for the modules, perform this task in privileged mode:
This example shows how to display the switch power environment for the modules:
Console> (enable) show environment power 2
Feature not supported on module 2.
Console> (enable)
Console> (enable) show environment power
PS1 Capacity:1153.32 Watts (27.46 Amps @42V)
PS2 Capacity:none
PS Configuration :PS1 and PS2 in Redundant Configuration.
Total Power Available:1153.32 Watts (27.46 Amps @42V)
Total Power Available for Line Card Usage:1153.32 Watts (27.46 Amps @42V)
Total Power Drawn From the System:683.76 Watts (16.28 Amps @42V)
Total Inline Power Drawn From the System: 57.54 Watts ( 1.37 Amps @42V)
Remaining Power in the System:469.56 Watts (11.18 Amps @42V)
Configured Default Inline Power allocation per port:15.400 Watts (0.36 Amps
@42V)
Slot power Requirement/Usage :
Slot Card Type PowerRequested PowerAllocated CardStatus
Watts A @42V Watts A @42V
---- ------------------- ------- ------ ------- ------ ----------
1 WS-X6K-SUP2-2GE 128.52 3.06 128.52 3.06 ok
2 0.00 0.00 128.52 3.06 none
3 WS-X6548-RJ-45 123.06 2.93 123.06 2.93 ok
4 WS-X6148-RJ45V 100.38 2.39 100.38 2.39 ok
6 WS-X6148-GE-TX 145.74 3.47 145.74 3.47 ok
Task Command
Display the switch power environment for the
modules.
show environment power [mod]
