55-24
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 55 Configuring a VoIP Network
Configuring VoIP on a Switch
These examples show how to configure the port voice interface for the DHCP, TFTP, and DNS servers:
Console> (enable) set port voice interface 7/1 dhcp enable
Port 7/1 DHCP enabled.
Console> (enable) set port voice interface 7/3 dhcp disable 171.68.111.41/24 tftp
173.32.43.11 dns 172.20.34.204 cisco.com
Port 7/3 dhcp disabled.
System DNS configurations applied.
Console> (enable) set port voice interface 7/4-6 dhcp enable vlan 3
Vlan 3 configuration successful
Ports 7/4-6 DHCP enabled.
Console> (enable)
Displaying a Port Voice Interface Configuration
To display a port voice interface configuration, perform this task in privileged mode:
This example shows how to display the port voice interface configuration (this display is from the
24-port FXS analog interface module):
Console> show port voice interface 5
Port DHCP MAC-Address IP-Address Subnet-Mask
-------- ------- ----------------- --------------- ---------------
5/1-24 disable 00-10-7b-00-13-ea 10.6.15.158 255.255.255.0
Port Call-Manager(s) DHCP-Server TFTP-Server Gateway
-------- ----------------- --------------- --------------- ---------------
5/1-24 10.6.15.155 - 10.6.15.155 -
Port DNS-Server(s) Domain
-------- ----------------- -------------------------------------------------
5/1-24 12.2.2.1* cisco.cisco.com
7.7.7.7
(*): Primary
Console> (enable)
Displaying the FDL Statistics
Note Facilities Data Link (FDL) is a link management protocol that is used to diagnose the problems and
gather the statistics.
To display the FDL statistics for the specified ports, perform this task in privileged mode:
Task Command
Display a port voice interface configuration. show port voice interface [mod[/port]]
Task Command
Display the FDL statistics for the specified ports. show port voice fdl [mod[/port]]
