Chapter 13 Configuring CEF for PFC2 and PFC3A
Understanding How Layer 3 Switching Works
Table 13-1 lists the adjacency types.
Enter the show mls entry cef adjacency command to display the following:
• FIB information (see the “Understanding the FIB” section on page 13-6)
• Adjacency type (connect, drop, null, loopbk, frc drp, punt, no r/w)
• Next-hop MAC address
• Next-hop VLAN
• Next-hop encapsulation
• Number of packets that are transmitted to this adjacency from the associated FIB entry
• Number of bytes that are transmitted to this adjacency from the associated FIB entry
Console> (enable) show mls entry cef adjacency
Mod: 15
Destination-IP: 140.140.1.5 Destination-Mask: 255.255.255.255
FIB-Type: resolved
AdjType NextHop-IP NextHop-Mac Vlan Encp Tx-Packets Tx-Octets
-------- --------------- ----------------- ---- ---- ------------ -------------
connect 140.140.1.5 00-00-d0-00-00-05 140 ARPA 0 0
Mod: 15
Destination-IP: 150.150.1.5 Destination-Mask: 255.255.255.255
FIB-Type: resolved
AdjType NextHop-IP NextHop-Mac Vlan Encp Tx-Packets Tx-Octets
-------- --------------- ----------------- ---- ---- ------------ -------------
connect 150.150.1.5 00-00-e0-00-00-05 150 ARPA 0 0
Mod: 15
Destination-IP: 153.153.1.5 Destination-Mask: 255.255.255.255
FIB-Type: resolved
AdjType NextHop-IP NextHop-Mac Vlan Encp Tx-Packets Tx-Octets
-------- --------------- ----------------- ---- ---- ------------ -------------
connect 153.153.1.5 00-00-e3-00-00-05 153 ARPA 0 0
.
.
.
Console> (enable)
Enter the clear mls entry cef adjacency command to clear the CEF adjacency information:
Console> (enable) clear mls entry cef adjacency
Adjacency statistics has been cleared.
Console> (enable)
Table 13-1 Adjacency Types
Adjacency Type Description
connect Entry type that contains complete rewrite information
punt Entry to send traffic to MSFC2/MSFC3
no r/w Entry to send traffic to MSFC2/MSFC3 when rewrite information is incomplete
frc drp Entry that is used to drop packets due to ARP throttling
drop, null, loopbk Entries that are used to drop packets
