14-9
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 14 Configuring MLS
Understanding How Layer 3 Switching Works
This example shows the output when NAT is configured on the MSFC:
Console> show mls flowmask
The MSFC features are using NotVlanFullFlow and VlanFullFlowOnly flow mask on vlan(s)
10-11,50-51,90-91.
Netflow Data Export is disabled
NDE Flowmask is configured to at least the Null flowmask
Console>
These examples show the output with various configurations when the reflexive ACL feature is
configured on the MSFC:
Console> show mls flowmask
The MSFC features are using VlanFullFlowOnly flow mask on vlan(s) 13.
Netflow Data Export is disabled
NDE Flowmask is configured to use at least Null flowmask
Console>
Console> show mls flowmask
The MSFC features are using VlanFullFlowOnly flow mask on vlan(s) 13.
Netflow Data Export is enabled and is using Full-Vlan flowmask
NDE Flowmask is configured to use at least Full-Vlan flowmask
Console>
Flow Mask Modes and show mls entry Command Outputs
With the destination-ip flow mask, the source IP, protocol, and source and destination port fields show
the details of the last packet that was Layer 3 switched using the MLS cache entry.
This example shows how the show mls entry command output appears in destination-ip mode:
Console> (enable) show mls entry ip short
Destination-IP Source-IP Prot DstPrt SrcPrt Destination-Mac Vlan
--------------- --------------- ----- ------ ------ ----------------- ----
ESrc EDst SPort DPort Stat-Pkts Stat-Byte Uptime Age
---- ---- ----- ----- --------- ------------ -------- --------
171.69.200.234 - - - - 00-60-70-6c-fc-22 4
ARPA SNAP 5/8 11/1 3152 347854 09:01:19 09:08:20
171.69.1.133 - - - - 00-60-70-6c-fc-23 2
SNAP ARPA 5/8 1/1 2345 123456 09:03:32 09:08:12
Total Entries: 2
* indicates TCP flow has ended
Console> (enable)
Note The short keyword exists for some show commands and displays the output by wrapping the text after
80 characters. The default is long (no text wrap).
With the source-destination-ip flow mask, the protocol, source port, and destination port fields display
the details of the last packet that was Layer 3 switched using the MLS cache entry.
