14-30
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 14 Configuring MLS
Configuring MLS
Displaying IP MLS Statistics by Protocol
The show mls statistics protocol command displays the IP MLS statistics by protocol (such as Telnet,
FTP, and WWW). The protocol keyword functions only if the flow mask mode is full flow. Enter the
show mls command to see the current flow mask.
To display the IP MLS statistics by protocol, perform this task in privileged mode:
This example shows how to display the IP MLS statistics by protocol:
Console> (enable) show mls statistics protocol
Protocol TotalFlows TotalPackets Total Bytes
------- ---------- -------------- ------------
Telnet 900 630 4298
FTP 688 2190 3105
WWW 389 42679 623686
SMTP 802 4966 92873
X 142 2487 36870
DNS 1580 52 1046
Others 82 1 73
Total 6583 53005 801951
Console> (enable)
Displaying Statistics for MLS Cache Entries
The show mls statistics entry command displays the IP MLS statistics for the MLS cache entries.
Specify the destination IP address, source IP address, protocol, and source and destination ports to see
the specific MLS cache entries.
A value of zero (0) for src_port or dst_port is treated as a wildcard, and all the statistics are displayed
(the unspecified options are treated as wildcards). If the protocol specified is not TCP or UDP, set the
src_port and dst_prt to 0 or no statistics will display.
To display the statistics for the MLS cache entries, perform this task in privileged mode:
This example shows how to display the statistics for a particular MLS cache entry:
Console> show mls statistics entry ip destination 172.20.22.14
Last Used
Destination IP Source IP Prot DstPrt SrcPrt Stat-Pkts Stat-Bytes
--------------- --------------- ---- ------ ------ --------- -----------
MSFC 127.0.0.12:
172.20.22.14 172.20.25.10 6 50648 80 3152 347854
Console>
Task Command
Display the IP MLS statistics by protocol
(only if IP MLS is in full flow mode).
show mls statistics protocol
Task Command
Display the statistics for the MLS cache
entries. If you do not specify an MLS cache
entry, all the statistics are shown.
show mls statistics entry ip [destination
ip_addr_spec] [source ip_addr_spec] [flow protocol
src_port dst_port]
