15-98
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 15 Configuring Access Control
Configuring Policy-Based Forwarding
Rolling Back Adjacency Table Entries in the Edit Buffer
You can clear the adjacency table entries in the edit buffer that were made prior to the last commit by
using the rollback command. The adjacency table entries are rolled back to their state at the last commit.
To roll back the adjacency table entries in the edit buffer, perform this task in privileged mode:
This example shows how to roll back the adjacency table entries in the edit buffer:
Console> (enable) rollback security acl adjacency
Editbuffer for adjacency info rolled back to last commit state.
Console> (enable)
Configuring Hosts for PBF
This section describes the host configuration procedures for the following platforms and operating
systems:
• Linux, page 15-98
• Sun Workstation, page 15-99
• MS-Windows/NT/2000 Hosts, page 15-100
Note When a router is not present in the network, you need to specify the static ARP entries on the
participating hosts. The host’s ARP table maps the IP address of the host device to the MAC address of
the PFC2 or PFC3A/PFC3B/PFC3BXL.
Note The IP addresses in the following examples are the IP addresses that are used in Figure 15-10. These IP
addresses were randomly selected; make sure that the IP addresses that you use in your network
configuration are unique.
Linux
These examples show how to configure the ARP table for the hosts that run the Linux operating system.
This example shows how to configure Host A:
arp -s 11.0.0.1 00:11:11:11:11:11 -i eth0
route add 11.0.0.1 eth0
This example shows how to configure Host B:
arp -s 10.0.0.1 00:11:11:11:11:11 -i eth1
route add 10.0.0.1 eth1
Task Command
Roll back the adjacency table entries in
the edit buffer.
rollback security acl {acl_name | all | adjacency}
