15-111
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 15 Configuring Access Control
Configuring Policy-Based Forwarding
Configuring the PBF Before Software Release 8.6(1)
To configure a PBF with a software release before release 8.6(1), follow these steps:
Step 1 Configure the PBF MAC address for the PFC and enable PBF.
Console> (enable) set pbf
PBF committed successfully.
Operation successful.
Console> (enable)
Console> (enable) show pbf
Pbf status Mac address Vlans
------------ ------------------ ------------------
ok 00-0d-65-36-1e-eb
Console> (enable)
Step 2 Configure one PBF client called CLIENT-TEST.
Console> (enable) set pbf client CLIENT-TEST 10.0.0.10 00-00-11-11-22-22 10
Commit operation successful.
Console> (enable)
The PBF client has been created
Console> (enable)
Console> (enable) show pbf client
Name : CLIENT-TEST
Map : No map
VLAN : 10
Clients : 1
Adjacency ip mac
-------------------------------------------------
.c0000CLIENT-TEST 10.0.0.10 00-00-11-11-22-22
Console> (enable)
The set pbf client command macro has created the security ACL adjacency for the client, but the macro
command (set pbf client CLIENT-TEST 10.0.0.10 00-00-11-11-22-22 10) that created the security
ACL adjacency does not appear in the following configuration:
Console> (enable) show run
<SNIP> Unrelated configuration information cut out
!
#security ACLs
clear security acl all
#pbf set
set pbf mac 00-0d-65-36-1e-eb
#adj set
set security acl adjacency .c0000CLIENT-TEST 10 00-00-11-11-22-22 10.0.0.10
#
commit security acl all
!
<SNIP> Unrelated configuration information cut out
Console> (enable)
