19-13

Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7

OL-8978-04

Chapter 19 Configuring Dynamic Port VLAN Membership with VMPS

Dynamic Port VLAN Membership with VMPS Configuration Examples

Figure 19-1 Dynamic Port VLAN Membership Configuration

Primary VMPS

Server 1

Secondary VMPS

Server 2

Secondary VMPS

Server 3

Catalyst 6500

series switches

Catalyst 6000

172.20.26.150

172.20.26.151

Catalyst 6500 series switches

172.20.26.152

Ethernet segment

172.20.26.153

172.20.26.154

172.20.26.155

172.20.26.156

172.20.26.157

172.20.26.158

172.20.26.159

Client

End station 2

End station 1

TFTP server

3/1

Switch 10

Switch 9

Switch 8

Switch 7

Switch 6

Switch 5

Switch 3

Switch 2

Switch 1

Switch 4

172.20.22.7

55908
