21-5
Catalyst 6500 Series Switch Software Configuration Guide—Release 8.7
OL-8978-04
Chapter 21 Configuring GOLD
Configuring Online Diagnostics
Note Not all functional test groups are present for every module because the supported functional test groups
vary depending on the module type. If you are not sure which functional test group to select, run all the
packet switching tests that are run during bootup when the diagnostic level is set to “complete” by
entering the diagnostic start module mod/num test complete command.
Note If you run the loopback test and it fails on one or several ports of a module, disconnect any cables that
are connected to the ports on that module, shut down all the ports on that module, and then rerun the
loopback test. It is possible that some spurious packets are interfering with the loopback test and causing
it to fail. Also, if the module has an inline-power daughter card, disable power to the inline-power
daughter card before running the test.
Additional test requirements are as follows:
• User actions before running the test—None
• User actions after running the test—None
Table 21-1 On-Demand Tests: Supervisor Engine
Functional Test Group Individual Tests
Per-port tests TestLoopback
Layer-2 forwarding tests TestNewIndexLearn
TestMatchCapture
TestDontConditionalLearn
TestProtocolMatchChannel
TestBadBpduTrap
NetFlow function TestNetflowInlineRewrite
ACL/QOS function TestAclPermit
TestQosTcam
TestAclDeny
IP version 4 function TestIPv4FibShortcut
TestFibDevices
TestL3Capture2
TestNATFibShortcut
Multicast function TestL3VlanMet
SPAN function TestIngressSpan
TestEgressSpan
Fabric connection TestFabricSnakeForward
TestFabricSnakeBackward
EOBC connection Proceed to Step 3
Packet Buffer issues Proceed to Step 4
