[The specification which depend on the model]
CT-S280/CT-S281/BD2-2220/PMU series/CT-P29x series
•Bit 2 of the 1st byte (printer information) of the status sent in 4 bytes is set to 00H because
drawer is not supported.
PMU2300III
• If the presenter function is valid, Bit 2 of the 2nd byte sent in 4 bytes status data is set to 04H
when presenter error occurs.
• If the presenter function is valid, Bit 3 of the 3rd byte sent in 4 bytes shows presenter sensor
status.
CT-S281
• Bit 0, 1 of the 3rd byte (Paper Sensor information) is set to 00H, if the Paper-end detector is uninstalled, or if
MSW2-8= 0.
•Bit 2, 3ofthe 3
rd
byte (Paper Sensor information): Whencover is open, paper endmaybe detected aswell.
CT-P29x series/CT-S310 II
•Bit 0, 1ofthe 3
rd
byte (Paper Sensor information): Bitisfixed at 0due tono papernear endfunction.
(1) 1st byte (Printer information)
Bit Status Hex. Decimal
0
Unused
00H 0
1
Unused
00H 0
Statusofpin 3of drawerkick-out connector= “L”
00H 0
2
Statusofpin 3of drawerkick-out connector= “H”
04H 4
Online status
00H 0
3
Offline status
08H 8
4
Unused
10H 16
Cover closed
00H 0
5
Cover open
20H 32
Not in paper feed state triggered byFEED switch
00H 0
6
Inpaperfeed state triggered byFEED switch
40H 64
7
Unused
00H 0
