dallmeier DLS 4 - UPS Configuration; Card Reader

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
107Dallmeier electronic
Fig. 14-12: Serial Interfaces dialog
Ø Select the Interface.
Ø Select UPS as the Function.
Ø Finally conrm with OK.
The dialog described below for conguring the UPS will then be displayed automatically.
14.6.2 UPSconguration
Ø Open the UPS dialog via Setup > Interfaces > UPS.
Fig. 14-13: UPS dialog
Ø Check the Enable UPS checkbox.
Ø Select the Manufacturer and Model.
Ø Finally conrm with OK.
14.7 Card reader
NOTE
The functionality for the connection of a card reader is not
integrated in the current version of the recorder software.
