dallmeier DLS 4 Installation And Configuration

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
53Dallmeier electronic
8.4.1 Manual and automatic mode
The following recording modes can be used with the various camera types in the manual
and automatic track modes:
l Permanent
l Motion
l Contact
8.4.1.1 Permanent
In the Permanent recording mode every image sent by the camera will be recorded.
Ø Ensure that the Expert Mode option is activated.
Ø Set the Permanent recording mode.
Ø Observe the explanations given below.
Fig. 8-17: Permanent recording mode
Ø Congure Private Zones if required (see chapter Basicconguration).
Ø Activate / congure the Camera Timer if required (see chapter Basicconguration).
Ø Activate the Use Database option if required.
Ø Activate the Set marker on Camera Contact option if required.
Ø Conrm with OK.
Database
In the default conguration it is possible to save certain information with the pictures in the
track (for example indices set using the Set marker on Camera Contact option). When the
Use Database option is activated this information additionally will be saved in a database.
The advantage of the database is demonstrated when playing back or searching within a
large track. A search for certain events is generally faster. This relates to the index search
and extended search functions.
The database is mandatory to save position date when the SmartFinder is used. The Use
Database checkbox for the appropriate camera will be checked automatically in this case
and cannot be unchecked.
Set marker on Camera Contact
A marker (index) will be saved to the track when a camera related contact IN function is
triggered. While playing back theses markings can be searched (index search and exten-
ded search).
