dallmeier DLS 4 Installation And Configuration

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
63Dallmeier electronic
The default settings will be adopted for all connected cameras. The memory will be assigned
in equal parts to every camera. Recording (permanent) will be activated for all connected
cameras.
Ø Congure the recording as described above.
8.6 Activation
Recording in a camera’s LP-track or S-track can be activated anytime. When no recording
conguration is done (see above) the default settings of the Permanent recording mode
will be valid.
Ø Left-click the corresponding recording button.
The button will be displayed in a color corresponding to the set recording mode.
Fig. 8-28: Recording buttons
Ø Proceed analogous for all relevant cameras.
Ø Finally conrm the Recording Settings dialog with OK.
8.7 Video memory
The recorder can be operated in three different track modes. These differ basically in regard
to the storage concept and therefore in regard to the conguration of the video memory.
8.7.1 Standard
In the Standard track mode every camera / track is assigned a particular part of the entire
video memory manually (track size).
IMPORTANT
In the Standard track mode all recordings need to be deleted
if the video memory conguration is modied..
8.7.1.1 Longplay tracks
The video memory for the single Longplay tracks is dened directly in the Recording Set-
tings dialog. This can be done with two variables:
No recording
Permanent
Motion
Contact
