DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
28Dallmeier electronic
Ø Enter the IP address of the DLS set as the Master with the virtual keyboard.
Ø A click on the button Ping starts a test of the connection.
7.2.3 USB radio clock
If a radio clock is used the DLS obtains the current time wirelessly and adjusts the system
time to it.
The USB DFM-1-USB radio clock is available for the DLS. Connect the DFM-1-USB to the
DLS.
Ø Check USB in the Radio Clock box in the Time dialog.
Fig. 7-5: Activate USB Radio Clock
Ø Conrm with OK.
Function display of the radio clock module
LED only illuminates green or only ashes red
= no reception.
LED only illuminates red, i.e. does not ash
= DFM-1-USB not connected correctly.
LED ashes regularly back and forth between red/green
= Reception OK.
Notes on time synchronization
Please ensure that the time is not corrected right away after some time has passed, as
is done with conventional radio clocks. The time in the DLS continuously approaches the
correct time until the DLS time is in sync with the radio signal. This process can last several
minutes.
The duration depends on the deviation between the set time and the radio time.
This procedure is a result of the time-dependent, internal program sequences of the DLS.
Changing the time quickly can cause an error in the sequence and thus a malfunction of
the DLS.
Possible problems and causes with date and time
Incorrect time is displayed:
Check the time zone setting.
Automatic switching from daylight-saving time to winter time does not occur:
The time will only be switched over automatically when a corresponding MET time zone
is selected, e.g. Europe/Berlin.
