DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
56Dallmeier electronic
Timer
The recording is started by the contact switching. Recording is stopped After the Contact
Recording Duration expired.
Toggle
The recording is triggered by the contact switching. It is stopped again by the same contact
switching again.
Marker
A marker (index) will be saved to the track when the contact is triggered. While playing back
theses markings can be searched (index search and extended search).
8.4.2 Standard mode
In Standard track mode the images from a camera can be recorded in the LP track and in
the S track. Thereby different recording modes may be used. The video quality settings
and the connection data are always valid.
The following recording modes can be used in the Standard track mode:
l Permanent
l Motion
l Contact
8.4.2.1 Permanent
In the Permanent recording mode every image sent by the camera will be recorded.
Ø Set the Permanent recording mode.
Ø Observe the explanations given below.
Fig. 8-20: Permanent recording mode
Ø Congure Private Zones if required (see chapter Basicconguration).
Ø Activate / congure the Timer if required (see chapter Basicconguration).
Ø Activate the Use Database option if required.
Ø Set an option (Event, Save, Mark) if required.
Ø Conrm with OK.
