dallmeier DLS 4 Installation And Configuration

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
84Dallmeier electronic
10.3.7 Activation
After its conguration the alarm host must be activated.
Ø Select an alarm host with a left click in the alarm host list.
Ø Activate the corresponding checkbox in the Active column.
Fig. 10-11
Ø Conrm with OK nally.
10.3.8 EBÜS
EBueS (uniform image transmission system / Einheitliches Bildübertragungssystem) is a
standardized transmission system for messages and images between a recorder and an
alarm host.
The recorder can send all messages concerning states and events (see chapter Alarm
hosts / Messages). Which messages actually will be processed and displayed by EBueS
depends on the EBueS server conguration. In order to avoid needless network trafc only
relevant messages should be sent.
NOTE
The EBueS… will only be displayed when the appropriate
function has been activated.
After the activation of EBueS the Zentrale 8 alarm host is prepared for this function.
Ø Select alarm host number 8.
The connection type Ethernet will be set automatically.
The EBueS… will be activated.
Fig. 10-12
Ø Click EBueS….
