dallmeier DLS 4 Installation And Configuration

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
68Dallmeier electronic
Decay time
The Decay time determines how long a motion event is valid. If an additional motion event
is detected in the same image section before this period expired, it will not be rated as a
new event.
This setting allows to reduce events that are caused by repeated motions of the same
object.
Validity period
This option is not integrated in the current version.
8.8.4 Camera control
Suitable dome / PTZ-cameras can be controlled and congured with the recorder’s graphical
user interface (see documentation Operation) or with a connected external PTZ keyboard
(see separate documentation). Depending on the camera various connection types can be
used:
l Connection via serial interface and a DNI (Dallmeier Network Interface)
l Direct connection via the serial interface.
l Connection via video cable with UTC.
Ø Left-click on the relevant control button.
Fig. 8-36: Camera control activation
The Control function will be activated with default settings for the corresponding camera.
The determination of the connection type is done in the Recording Settings (sub) dialog.
Ø Right-click on the relevant control button.
The Recording Settings (sub) dialog will be displayed. The available connection types
depend on the serial interface settings.
Fig. 8-37: Connection setting
Ø Select the relevant connection to the camera.
Complete the camera control conguration as described in the chapters Congurationof
optional periphery / functions.
