dallmeier DLS 4 - 11 Serial Interface; Setting; Functions

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
87Dallmeier electronic
11 Serial Interface
11.1 Setting
Ø Open the Serial Interfaces dialog via Setup > Interfaces > Serial to congure the serial
interface (COM1).
Fig. 11-1: Serial Interfaces dialog
Ø Dene the Function of the interface.
NOTE
Additional settings may be required for some functions. See the
documentation supplied with the connected device for details
of these values.
Ø Conrm with OK.
11.2 Functions
NOTE
The available functions of the interface depend on various soft-
ware and hardware options. The scope of functions depends on
the ordered version, not on the content of the documentation.
