dallmeier DLS 4 Installation And Configuration

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
15Dallmeier electronic
Reliable earthing
Ensure a reliable earthing of the DLS. Use power strips when other supply connections than
direct connections to the branch circuit are being used.
4.3.2 Mounting
Ø Remove the four side housing screws.
Fig. 4-2
Ø Place the two 19“ mountings against the housing.
Fig. 4-3
Ø Secure the 19“ mountings to the housing using the removed screws.
Ø Install the device in the 19“ rack.
IMPORTANT
Follow the instructions supplied by the rack manufacturer.
Ø Do not mount the DLS upside down.
Ø Ensure a stable and horizontal mounting.
Ø Ensure sufcient ventilation with 4 inch free space on the DLS front, rear and right
side.
Ø Establish the required connections as described in the following.
Ø Start-up and login for conguration as described in the following.
