dallmeier DLS 4 Installation And Configuration

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
111Dallmeier electronic
Functions
1 Zoom In 5 Position query
2 Zoom Out 6 Preset 1 to 3
3 Zoom control 7 Menu on/off
4 Preview window 8 Reset settings
15.2.3 Zoom function
Ø By clicking on Zoom in (1) you can reduce a picture section in 11 stages in digital form.
Clicking on Zoom out (2) increases the size of the picture section.
The position of the section in the full picture is displayed in the preview window with a
border.
Ø If the mouse pointer is inside the rectangle, you can position the zoom area (A) whilst
holding the mouse button.
Fig. 15-6
Ø Click on the Center button (B) to reset your zoom setting.
15.2.3.1 Save zoom factor and position
A selected zoom factor and the position of the picture section can be saved and opened
using one of the eight buttons (next to the preview picture).
Ø Select a picture section and denes its position.
Ø Go to one of the buttons with the mouse pointer and right-click on it.
Ø Select Save Position.
1 4 6 7
8523
Fig. 15-5
B A
