DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
59Dallmeier electronic
Ø Set the Pre-Event time (see above).
Ø Congure Private Zones if required (see chapter Basicconguration).
Ø Activate / congure the Timer if required (see chapter Basicconguration).
Ø Activate the Use Database option if required.
Ø Set the Options for contact recording.
Ø Set the Contact Recording Duration if required.
Ø Conrm with OK.
Normal Single
A contact triggers the recording of an individual picture.
Normal sequencer
The recording is triggered by the contact switching. It continues until the contact is released
again.
Start
The recording is triggered by the contact switching. The recording is stopped by an opposite
contact function (Stop recording (Contact recording mode)) or Stop recording camera
(Contact recording mode)).
Timer
The recording is started by the contact switching. Recording is stopped after the Contact
Recording Duration expired.
Toggle
The recording is triggered by the contact switching. It is stopped again by the same contact
switching again.
Mark
A marker (index) will be saved to the track when the contact is triggered. While playing back
theses markings can be searched (index search and extended search).
NOTE
The options Event and Save are not relevant in the Contact
recording mode.
8.5 Video quality
Note that for technical reasons it is not possible to use every setting combination. There
are dependencies between the single settings. In addition they depend on the number of
channels (cameras) used, the recorder model and the video standard (PAL/NTSC).
Incorrect congurations will be compensated by automatically adjusting of the values. In some
cases the track size has to be reduced or the number of available channels adjusted.
8.5.1 Manual and automatic mode
Recording modes with video quality switching are available in these track modes. In this
case the following settings have to be made on the tab Quality. The procedure is the same
as described in the following.
