dallmeier DLS 4 Installation And Configuration

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
112Dallmeier electronic
Fig. 15-7
15.2.3.2 Enter name for position
Ø Right-click again on the button under which you have saved the position.
Ø Select Change Name.
You can x up to eight picture sections for each camera.
Fig. 15-8
Ø By clicking on one of the buttons you can select the appropriate section directly.
15.2.4 Congurecamera
If you wish to adjust the settings of the camera to the local conditions, access to the camera
menus is required.
Ø Click on Open/Close menu.
Fig. 15-9
The camera menu is display in the picture and the relevant control elements are activated
in the control panel.
