Functions Explanation
None The interface is deactivated.
Commanding This function allows the recorder to be controlled by an
external application / device via the serial interface (DaVid
protocol). Control commands are only received, however,
no conrmation is returned.
Commanding with acknow-
ledgement
This function is identical to the Commanding function
hereby in this case after each control command conr-
mation will be sent to the application / device to which the
command relates.
Mouse This setting allows the connection of a serial mouse. This
is only advisable if mouse control over a long distance (up
to 100 m) is required. This can not be achieved using a
PS/2 or USB mouse.
Transparente data channel/
Direct camera control
Using this function data can be sent via the recorder to
another device. The data then arrive at the receiver in
exactly the same form as they were sent by the transmitter
(transparent data channel).
This is used, for example, to send control signals from
PView via LAN to the recorder. This then forwards them
to a controllable camera via the serial port.
In the opposite direction, conrmation signals from the
camera are read at the serial port and sent via LAN to
PView.
DNI (external system) This setting allows an external system to be connected
for example an automatic teller machine (ATM), access
control system or a Huth cash desk via a Dallmeier Net-
work Interface (DNI-1).
UPS This function allows communication with an uninterrupti-
ble power supply unit (UPS). This means that messages
can be sent from the UPS (for example charge status of
the battery) to the recorder where they can be output or
processed.
DNI (camera control) This function allows the connection of an external control
desk or a dome camera via a Dallmeier Network Interface
(DNI-1).
