dallmeier DLS 4 Installation And Configuration

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
67Dallmeier electronic
Note that . . .
. . . the function is not suitable for dome/PTZ cameras.
. . . the camera has to be mounted vibration-free.
. . . displaying and sending of a message is not intended.
. . . the Use Database option automatically will be activated for the relevant camera.
. . . the Search Criteria / Movement coordinates option automatically will be activated.
. . . alternating ambient conditions (brightness, precipitation) can cause false messages.
Ø Left-click the relevant SmartFinder button.
Fig. 8-34: SmartFinder activation
The SmartFinder function will be activated with default settings for the corresponding
camera. The conguration of the SmartFinder function is done in the Settings for Smart-
Finder dialog.
Ø Right-click the relevant SmartFinder button.
The Settings for SmartFinder dialog will be displayed.
Fig. 8-35: SmartFinder conguration
Ø Observe the explanations given below.
Ø Set the Sensitivity.
Ø Set the Decay time.
Ø Finally conrm with OK.
Sensitivity
The Sensitivity refers to the acceptable deviance between the compared images.
If the Sensitivity is set very high, a minor deviance is enough to detect a motion event.
In this case small motions can be detected. But minor deviances often are caused by al-
ternating ambient conditions (brightness, precipitation). Many false messages have to be
anticipated.
If the Sensitivity is set very low, the images have to differ very much. Only distinct motions
will be rated as an event. But only few false messages can be anticipated.
