dallmeier DLS 4 Installation And Configuration

DLS 4 / DLS 8 / 8 PLUS / DLS 16 / 16 PLUS
48Dallmeier electronic
Ø Open the Camera Timer dialog via Setup > Recording > Camera Timer.
Fig. 8-8: Camera Timer dialog
Ø Select the relevant camera in the Cameras section.
Ø Set Active and Inactive times as described in the following.
Ø Set Exceptions as described in the following.
Ø Proceed analogous for all relevant cameras.
Ø Finally conrm with OK.
NOTE
When changing the track mode, the camera timer will be reset.
Active und inactive times
The timer is based on a week schedule that is divided into 15 minute periods. In default
conguration no inactive times are dened.
Ø Ensure that the Standard option is selected.
Ø Select setting of active or inactive periods (A).
Fig. 8-9: Inactive times
