8-13 Configurable Status Word STW
Option: Function:
[71] Logic Rule 1 If Logic Rule 1 is evaluated as TRUE, the
input will go high. Otherwise, it will be
low.
[72] Logic Rule 2 If Logic Rule 2 is evaluated as TRUE, the
input will go high. Otherwise, it will be
low.
[73] Logic Rule 3 If Logic Rule 3 is evaluated as TRUE, the
input will go high. Otherwise, it will be
low.
[74] Logic Rule 4 If Logic Rule 4 is evaluated as TRUE, the
input will go high. Otherwise, it will be
low.
[75] Logic Rule 5 If Logic Rule 5 is evaluated as TRUE, the
input will go high. Otherwise, it will be
low.
[80] SL digital out A SL Controller Action. The input will go
high whenever the Smart Logic Action
[38] Set dig. out. A high is executed. The
input will go low whenever the Smart
Logic Action [32] Set dig. out. A low is
executed.
[81] SL digital out B SL Controller Action. The input will go
high whenever the Smart Logic Action
[39] Set dig. out. A high is executed. The
input will go low whenever the Smart
Logic Action [33] Set dig. out. A low is
executed.
[82] SL digital out C SL Controller Action. The input will go
high whenever the Smart Logic Action
[40] Set dig. out. A high is executed. The
input will go low whenever the Smart
Logic Action [34] Set dig. out. A low is
executed.
[83] SL digital out D SL Controller Action. The input will go
high whenever the Smart Logic Action
[41] Set dig. out. A high is executed. The
input will go low whenever the Smart
Logic Action [35] Set dig. out. A low is
executed.
[84] SL digital out E SL Controller Action. The input will go
high whenever the Smart Logic Action
[42] Set dig. out. A high is executed. The
input will go low whenever the Smart
Logic Action [36] Set dig. out. A low is
executed.
[85] SL digital out F SL Controller Action. The input will go
high whenever the Smart Logic Action
[43] Set dig. out. A high is executed. The
8-13 Configurable Status Word STW
Option: Function:
input will go low whenever the Smart
Logic Action [37] Set dig. out. A low is
executed
[86] ATEX ETR cur.
alarm
Selectable if par. 1-90 is set to [20] or [21].
If the alarm 164 ATEX ETR cur.lim.alarm is
active, the output will be 1.
[87] ATEX ETR freq.
alarm
Selectable if par. 1-90 is set to [20] or [21].
If the alarm 166 ATEX ETR freq.lim.alarm is
active, the output will be 1.
[88] ATEX ETR cur.
warning
Selectable if par. 1-90 is set to [20] or [21].
If the alarm 163 ATEX ETR cur.lim.warning
is active, the output will be 1.
[89] ATEX ETR freq.
warning
Selectable if par. 1-90 is set to [20] or [21].
If the warning 165 ATEX ETR
freq.lim.warning is active, the output will
be 1.
[90] Safe Function
active
[91] Safe Opt. Reset
req.
8-14 Configurable Control Word CTW
Option: Function:
Selection of control word bit 10 if it is active
low or active high
[0] None
[1] * Profile
default
[2] CTW Valid,
active low
[3] Safe Option
Reset
[4] PID error
inverse
When enabled, it inverts the resulting error
from the process PID controller. Available
only if "Configuration Mode" is set to
"Surface Winder," "Extended PID Speed OL"
or "Extended PID Speed CL."
[5] PID reset I
part
When enabled, resets the I-part of the
process PID controller. Equivalent to
7-40 Process PID I-part Reset. Available only if
"Configuration Mode" is set to "Surface
Winder," "Extended PID Speed OL" or
"Extended PID Speed CL."
[6] PID enable When enabled, enables the extended
process PID controller. Equivalent to
7-50 Process PID Extended PID. Available only
if "Configuration Mode" is set "Extended PID
Speed OL" or "Extended PID Speed CL."
Parameter Descriptions FC 300 Programming Guide
MG33MD22 - VLT
®
is a registered Danfoss trademark 3-87
