3.13.4 12-3* EtherNet/IP
12-30 Warning parameter
Range: Function:
[0000–
FFFF hex]
Read only. Displays the EtherNet/IP specific 16-bit
status word.
Bit Description
0 Owned
1 Not used
2 Configured
3 Not used
4 Not used
5 Not used
6 Not used
7 Not used
8 Minor recoverable fault
9 Minor unrecoverable fault
10 Major recoverable fault
11 Major unrecoverable fault
12 Not used
13 Not used
14 Not used
15 Not used
12-31 Net Reference
Option: Function:
Read only. Displays the reference source in Instance
21/71.
[0] * Off Reference from the network is not active.
[1] On Reference from the network is active.
12-32 Net Control
Option: Function:
Read only. Displays the control source in Instance
21/71.
[0] * Off Control via the network is not active.
[1] On Control via the network is active
12-33 CIP Revision
Option: Function:
Read only. Displays the CIP version of
the option software.
[0] Major version (00–99)
[1] Minor version (00–99)
12-34 CIP Product Code
Range: Function:
1100 (FC 302) 1110
(FC 301)*
[0 – 9999] Read only. Displays the CIP
product code.
12-37 COS Inhibit Timer
Range: Function:
[0–65.535
ms]
Read-only Change-Of-State inhibit timer. If the
option is configured for COS operation, this
inhibit timer can be configured in the Forward
Open message to prevent that continuously
changing PCD data generates extensive network
traffic. The inhibit time is in milliseconds, 0 =
disabled.
12-38 COS Filters
Range: Function:
[[0–9] Filter 0–9
(0000–FFFFhex)]
Change-Of-State PCD filters. Sets up a
filter mask for each word of process data
when operating in COS mode. Single bits
in the PCDs can be filtered in/out.
12-50 Configured Station Alias
Range: Function:
0* [0 - 65535 ] The parameter shows the configured EtherCAT
station alias for the Adjustable frequency drive.
Changes will first be active after a power cycle.
12-51 Configured Station Address
Range: Function:
0* [0 - 65535 ] The parameter shows the configured station
address. The parameter can only be set by the
master at power-up.
12-59 EtherCAT Status
Range: Function:
0* [0 - 4294967295 ] This parameter contains status
information on the EtherCAT interface.
Refer to the EtherCAT manual for
detailed information.
12-80 FTP Server
Option: Function:
[0] * Disable Disables the built-in FTP server.
[1] Enable Enables the built-in FTP server.
12-81 HTTP Server
Option: Function:
[0] * Disable Disables the built-in HTTP (web) server.
[1] Enable Enables the built-in HTTP (web) server.
12-82 SMTP Service
Option: Function:
[0] * Disable Disables the SMTP (e-mail) service on the option.
[1] Enable Enables the SMTP (e-mail) service on the option.
Parameter Descriptions FC 300 Programming Guide
MG33MD22 - VLT
®
is a registered Danfoss trademark 3-107
