9-28 Process Control
Option: Function:
Process control (setting of the control word,
speed reference, and process data) is possible
via either Profibus or standard serial communi-
cation bus but not both simultaneously. Local
control is always possible via the LCP. Control
via process control is possible via either
terminals or serial communication bus
depending on the settings in 8-50 Coasting
Select to 8-56 Preset Reference Select.
[0] Disable Disables process control via Profibus, and
enables process control via standard serial
communication bus or Profibus Master class 2.
[1] * Enable
cyclic
master
Enables process control via Profibus Master Class
1, and disables process control via standard
serial communication bus or Profibus Master
class 2.
9-44 Fault Message Counter
Range: Function:
0* [0 - 65535 ] This parameter displays the number of error
events stored in 9-45 Fault Code and 9-47 Fault
Number. The maximum buffer capacity is eight
error events. The buffer and counter are set to
0 upon reset or power-up.
9-45 Fault Code
Range: Function:
0* [0 - 0 ] This buffer contains the alarm word for all alarms
and warnings that have occurred since the last
reset or power-up. The maximum buffer capacity is
eight error events.
9-47 Fault Number
Range: Function:
0* [0 - 0 ] This buffer contains the alarm number (e.g., 2 for
live zero error, 4 for line phase loss) for all alarms
and warnings that have occurred since last reset or
power-up. The maximum buffer capacity is eight
error events.
9-52 Fault Situation Counter
Range: Function:
0* [0 - 1000 ] This parameter displays the number of error
events which have occurred since the last reset
of power-up.
9-53 Profibus Warning Word
Range: Function:
0 * [0 - 65535 ] This parameter displays Profibus communi-
cation warnings. Please refer to the Profibus
Instruction Manual for further information.
Read only
Bit: Meaning:
0 Connection with DP master is not ok
1 Not used
2 FDLNDL (Serial Communication Bus Data link Layer) is
not ok
3 Clear data command received
4 Actual value is not updated
5 Baudrate search
6 PROFIBUS ASIC is not transmitting
7 Initialization of PROFIBUS is not ok
8 Adjustable frequency drive is tripped
9 Internal CAN error
10 Wrong configuration data from PLC
11 Wrong ID sent by PLC
12 Internal error occured
13 Not configured
14 Timeout active
15 Warning 34 active
9-63 Actual Baud Rate
Option: Function:
This parameter displays the actual
Profibus baud rate. The Profibus
Master automatically sets the baud
rate.
[0] 9,6 kbit/s
[1] 19,2 kbit/s
[2] 93,75 kbit/s
[3] 187,5 kbit/s
[4] 500 kbit/s
[6] 1500 kbit/s
[7] 3000 kbit/s
[8] 6000 kbit/s
[9] 12000 kbit/s
[10] 31,25 kbit/s
[11] 45,45 kbit/s
[255] * No baudrate found
9-64 Device Identification
Range: Function:
0* [0 - 0 ] This parameter displays the device identification.
Please refer to the Instruction Manual for Profibus,
MG.33.CX.YY for further explanation.
Parameter Descriptions FC 300 Programming Guide
3-98 MG33MD22 - VLT
®
is a registered Danfoss trademark
3
