Unit Type Speed Relation
Dimensionless
Linear
Speed
Flow, volume
Flow, mass
Velocity
Length
Temperature
Pressure Quadratic
Power Cubic
0-30 Unit for User-defined Readout
Option: Function:
It is possible to program a value to be shown in
the display of the LCP. The value will have a
linear, squared or cubed relation to speed. This
relation will depend on the unit selected (see
table above). The actual calculated value can be
read in 16-09 Custom Readout, and/or shown in
the display by selecting Custom Readout [16-09]
in 0-20 Display Line 1.1 Small to 0-24 Display Line 3
Large.
[0] * None
[1] %
[5] PPM
[10] 1/min
[11] rpm
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
0-30 Unit for User-defined Readout
Option: Function:
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[180] HP
0-31 Min Value of User-defined Readout
Range: Function:
0.00 Custom-
ReadoutUnit*
[Application
dependant]
This parameter sets the min.
value of the custom defined
readout (occurs at zero speed).
Only possible to set different
from 0 is when selecting a
linear unit in 0-30 Unit for User-
defined Readout. For quadratic
and cubic units, the minimum
value will be 0.
0.00 Custom-
ReadoutUnit*
[Application
dependant]
This parameter sets the min.
value of the custom defined
readout (occurs at zero speed).
Only possible to set different
from 0 is when selecting a
linear unit in 0-30 Unit for User-
defined Readout. For quadratic
and cubic units, the minimum
value will be 0.
0-32 Custom Readout Max Value
Range: Function:
100.00 Custom-
ReadoutUnit*
[ par. 0-31 -
999999.99
CustomRea-
doutUnit]
This parameter sets the max
value to be shown when
the speed of the motor has
reached the set value for
4-13 Motor Speed High Limit
[RPM] or 4-14 Motor Speed
High Limit [Hz] (depends on
setting in 0-02 Motor Speed
Unit).
Parameter Descriptions FC 300 Programming Guide
MG33MD22 - VLT
®
is a registered Danfoss trademark 3-9
3
3
